BATHROOM FAN CATA UC 12 STD BLACK
- DIAMETER : 120 mm
- DEBIT : 205 m3/h
- NOISE LEVEL : 47 dB
- COLOUR : ЧЕРЕН
- VALVE
CATA UC 12 STD BLACK Bathroom Extractor Fan, Ø120 mm, 205 m³/h, IP44
Helicocentrifugal impeller and built-in backdraught valve for Ø120 mm ducts.
The CATA UC 12 STD BLACK bathroom extractor fan connects to a 120 mm duct and mounts on either the wall or the ceiling. It moves 205 m³/h at 14 W of input power, with IP44 protection and double insulation for damp rooms. Fan speed is adjustable between 1000 and 2200 rpm.
205 m³/h airflow that clears steam quickly
A helicocentrifugal impeller and shaped plastic housing sustain the airflow even on longer duct runs. The declared noise level is 47 dB, comfortable for everyday use after a shower or in a WC.
IP44 and double insulation for wet rooms
The housing is protected against splashing water from any direction, and double insulation removes the need for an earth connection. Power supply is 220–240 V, 50/60 Hz.
Backdraught valve stops reverse airflow
The valve closes when the motor stops, blocking odours travelling back along a shared ventilation shaft. It is particularly useful in multi-apartment risers.
Removable front panel for cleaning
The front panel clips off and back on without tools, so dust on the grille and impeller comes off during routine bathroom cleaning. The black finish belongs to CATA's UC (Ultra Comfort) line.
Specifications
Main
Performance
Power and supply
| Brand | CATA |
| MODEL | UC 12 STD BLACK |
| DIAMETER | 120 mm |
| DEBIT | 205 m3/h |
| NOISE LEVEL | 47 dB |
| COLOUR | ЧЕРЕН |
| VALVE | Yes |
| WARRANTY | 24 MONTHS |
| EAN | 8436618650054 |
