БОЙЛЕР ELDOM WVF08039F 80 L
- CAPACITY : 80 L
- TANK CAPACITY : 75.0 L
- HEIGHT : 113.00 см
- DIAMETER SM : 39.0 см
- TYPE : ВЕРТИКАЛЕН
- TANK TYPE : GLAZED
- HEATER TYPE : COPPER
- WARRANTY : 60 MONTHS
ELDOM WVF08039F 80 L Water Heater, 3 kW, Wall-Mounted Vertical, Enamelled Tank
Six-level protection and 33 mm HFO closed-cell insulation keep heat where you need it.
The ELDOM WVF08039F is a wall-mounted vertical electric water heater in the 80 L class, with 75 L of usable capacity. Its 387 mm diameter fits narrow bathroom niches, while the external capillary thermostat is adjusted from the front panel.
Six-level tank and safety protection
The tank interior is coated with zirconium enamel under ELDOM's SHIELD process, and two magnesium anodes guard the full volume against corrosion. A reinforced flange, a capillary thermal cut-out and a combined metal valve with non-return and safety function cover overpressure and overheating.
ECO setting at 60 °C for lower running costs
The HFO closed-cell insulation is over 33 mm thick, limiting standby losses between heating cycles. Declared annual consumption is 1375 kWh on the M load profile, typical for an average household.
Twin LED indicator and temperature scale
A red light means the heater is working; white means the set temperature has been reached. The panel scale shows how far heating has progressed, and a single combined knob switches the unit on and sets the temperature.
Holiday mode and anti-bacterial heating
In Holiday mode the thermostat keeps the water above 5 °C, protecting the system in an unoccupied home during winter. Set to maximum, the thermostat raises the temperature high enough to kill bacteria in the tank. IP24 rating allows installation in damp rooms.
3 kW copper immersion element
The immersion tube element is designed and made by ELDOMINVEST. At 3 kW the unit sits at the top of the range normally offered for single-phase domestic heaters and delivers around 142 l of mixed water at 40 °C after a full heat-up.
Specifications
Main
Power and supply
Dimensions and weight
Materials
In the box
| Brand | ELDOM |
| MODEL | WVF08039F |
| CAPACITY | 80 L |
| TANK CAPACITY | 75.0 L |
| HEIGHT | 113.00 см |
| DIAMETER SM | 39.0 см |
| TYPE | ВЕРТИКАЛЕН |
| TANK TYPE | GLAZED |
| HEATER TYPE | COPPER |
| THERMOREGULATOR | МЕХАНИЧЕН |
| NOMINAL POWER KW | 3 |
| ELECTRICAL POWER TYPE | MONOPHASIC |
| ANNUAL ENERGY CONSUMPTION | 1375 |
| HEAT EXCHANGER | No |
| WARRANTY | 60 MONTHS |
| EAN | 3800035780529 |
